New redwood sat issues??

[Bobaru]

Just purchased a 2021 and cannot get the sat to connect thru any of the key tv ports. The sat will connect directly from dish to the receiver. I have tried two new dish receivers and dishes and they both are the same. Any ideas??
Thanks

[ljvda1221@gmail.com]

Originally Posted by Bobaru

Just purchased a 2021 and cannot get the sat to connect thru any of the key tv ports. The sat will connect directly from dish to the receiver. I have tried two new dish receivers and dishes and they both are the same. Any ideas??
Thanks

Bobaru, what model RW are you in and can you give a little more detail how you're connecting your system?

[Bobaru]

It’s a 4001lk. I have tried every scenario. Three foot coaxial from dish to roof top plug and then a three foot coaxial inside water compartment from roof junction to the key tv hook up and obviously from wall plate to the receiver.
I have also tried from the dish with twenty- five foot coaxial to every key tv plug on the outside and nothing. The only way it works is directly from the dish into the receiver.
Thanks

[ljvda1221@gmail.com]

And the key tv connector by the water, the blue light is on, yes?

[Bobaru]

Yes that stays o. I even pulled that out to make sure all cables were secure on the back

[ljvda1221@gmail.com]

Originally Posted by Bobaru

Yes that stays o. I even pulled that out to make sure all cables were secure on the back

Yeah if it was off I would've had you check that.

We're on the road now so let me mull that one over a little more til we reach our next destination.

Unrelated to this, have you figured out what the unlabeled black rocker switch in the storage bay is? Its under the in house vacuum system, set of three switches and its the third switch labeled on/off.

Thanks

[Bobaru]

Yes those are your outside light switches

[ljvda1221@gmail.com]

The first two we know for sure are the outside lights but the third didnt do anything for us.

[Jim & Mary]

We have a much older unit that yours, but Redwood ran dedicated coax runs (orange) for the satellite from the roof to the entertainment center and also to the bedroom. Those orange coaxes were exclusively for the rooftop satellite. There was a waterproof cap on the roof in front of the rear AC where the dish connections were made.

[Wolfyukon]

Bob,
You mention connecting the dish to the rooftop connection? Not sure what you mean by that. Are you referring to the Key TV port by the water nautilus system? Your satellite dish should connect there to the sat connection, then any interior Key TV plate- connect to your receiver(assume it is like a Wally), then an HDMI to the TV. Think that is what you have tried but just double checking...

[Bobaru]

The redwood that I bought has a pre-wired sat port on the roof top for a fixed dish. That port runs directly to another port in the water hook-up area isolated from the key tv ports. In any event I have tried hooking the dish directly to the key tv in that area as well as the storage area key tv . Still nothing.
Thanks

[Wolfyukon]

Got it. The Key TV ports in the water bay are the "ins" so screwy that when you hook the sat up to that and then the receiver to a sat in the inside it does not work.
Have you tried hooking the dish up to the Cable/Ant in the water bay and then the receiver in the coach to a cable/ant connection? Just spitballing here but might be something in the Sat cabling???

[Bobaru]

I have tried everything, I’m suspecting a break in cable or perhaps a screw or something. Can’t get any help from the dealer or redwood shy of hauling two hours back to the dealer and they knew nothing about the unit when I purchased it and now they don’t even call me back. I suggested to keystone that they should train their dealers before allowing them to sell units they know NOTHING about. Only owned the unit for one week! Frustrating!!
Thanks again

[Wolfyukon]

Hear that. We are 1 week tomorrow and already have 13 issues to discuss with Keystone owner relations tomorrow. 2021 4001LK like yours, with every available option and yet I have to ask what a switch is for in the basement bay because the dealer did not know...Feel your pain!

[Bobaru]

Just FYI for any following thread, I found the key tv booster to be bad even though it’s new and the blue led is on. Removed the booster and direct connected the sat to the coaxial behind it and works great!

[mhs4771]

The Key System has been used in Montana's for a while now and there is nothing but problems and issues with it. Very sorry to see they have now stuck it in Redwoods.
I understand they're trying to make things simpler and easier, but it appears the Key System is not the answer.

[travelin' texans]

I read this & a couple other different forums & it seems that 6 out of 10 post are asking for help with KeyTv or the InCommand systems.

[Jim & Mary]

Man, I'm so glad we have analog switches and non electronic cable tv and satellite tv. We've owned ours since the spring of 2013 and the switches work every single time....................and our Dish Travel'r had worked flawlessly for that entire time.
